Specifications

PRICING

Price	Standard
Price - Warranty (Months)	6
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Brand Name	ProStar™
Engine - Engine Type	Parallel Twin
Engine - Cylinders	2
Engine - Engine Stroke	4-Stroke
Engine - Horsepower (bhp)	181
Engine - Horsepower (kW)	135.1
Engine - Cooling	Liquid
Engine - Valves	8
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	DOHC
Engine - Bore (mm)	93
Engine - Bore (in)	3.66
Engine - Stroke (mm)	68
Engine - Stroke (in)	2.68
Engine - Displacement (cc)	925
Engine - Displacement (ci)	56.4
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Engine - Turbocharged	Yes
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Fuel Injector	Yes
Carburetion - Carburetor	No
Carburetion - Number Of Carburetors	0
Carburetion - Carburetion Type	Fuel Injected
Parental Controls - Speed Governor	No

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Continuously Variable (CVT)
Transmission - Primary Drive (Rear Wheel)	Shaft
Transmission - Primary Drive (Engine / Transmission)	Belt
Transmission - Reverse	Yes
Transmission - Transmission Brand	Polaris Variable Transmission (PVT)
Transmission - Hi / Low Range	Yes
Transmission - Primary Drive (Front Wheel)	Shaft

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	126.1
Dimensions - Length (mm)	3200
Dimensions - Width (in)	64
Dimensions - Width (mm)	1630
Dimensions - Height (in)	71.7
Dimensions - Height (mm)	1820
Dimensions - Wheelbase (in)	96
Dimensions - Wheelbase (mm)	2440
Dimensions - Ground Clearance (in)	14.5
Dimensions - Ground Clearance (mm)	368
Dimensions - Length (ft)	10.51
Dimensions - Length (ft/ft)	10
Dimensions - Length (ft/in)	6.1
Weight	Standard
Weight - Dry Weight (lbs)	1736
Weight - Dry Weight (kg)	789.2
Weight - Payload Capacity (lbs)	740
Weight - Payload Capacity (kgs)	336
Capacities	Standard
Capacities - Fuel Capacity (gal)	12
Capacities - Fuel Capacity (l)	45.4
Performance	Standard
Performance - Engine Displacement to Weight (cc)	0.53

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Exterior Guards	Standard
Exterior Guards - Chain Guard	No
Exterior Guards - Engine Case Guard	No
Exterior Guards - Exhaust Guard	No
Exterior Guards - Rear Mud Guards	No
Exterior Covers	Standard
Front Bumper	Standard
Front Fender Flairs	Standard
Rear Fender Flairs	Standard
Skid Plate	Standard
Skid Plate - Bash Plate (Front)	Yes
Cab Cage	Standard
Cab Rollbar	Standard
Cab Doors	Standard
Cab Doors - Cab Door Material	Hard
Cab Doors - Camouflage	No
Cab / Bed Divider	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Independent Double A-Arm
Front Suspension - Front Travel (in)	17
Front Suspension - Front Travel (mm)	432
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Front Suspension - Front Suspension Brand Name	Walker Evans®
Front Suspension - Front Stabilizer Bar	Yes
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Independent
Rear Suspension - Rear Travel (in)	20
Rear Suspension - Rear Travel (mm)	508
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Number Rear Shock Absorbers	2
Rear Suspension - Rear Suspension Brand Name	Walker Evans®
Rear Suspension - Rear Suspension Material	Steel
Rear Suspension - Rear Stabilizer Bar	Yes
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Front Wheel Width (in)	6
Wheels - Rear Wheel Width (in)	7
Wheels - Front Tire Diameter (in)	30
Wheels - Rear Tire Diameter (in)	30
Tires	Standard
Tires - Tire Brand	Maxxis®
Tires - Front Tire Width	10
Tires - Front Wheel Diameter	14
Tires - Rear Tire Width	10
Tires - Rear Wheel Diameter	14
Tires - Front Tire (Full Spec)	Maxxis® Carnivore: 30 x 10-14
Tires - Rear Tire (Full Spec)	Maxxis® Carnivore: 30 x 10-14

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Rear Brake Type	Hydraulic Disc

SEATS

Seat	Standard
Seat - Seat Type	Bucket
Seat - Seat Material	Vinyl
Seat - Folding	No
Seat - Headrest	Yes
Seat Specifications	Standard
Seat Specifications - Number Of Seats	2
Seat Specifications - Number Of Rows	1
Grab Rail or Strap	Standard

INSTRUMENTATION

Digital Instrumentation	Standard
Clock	Standard
Tachometer	Standard
Trip Odometer	Standard
Speedometer	Standard
Hour Meter	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Gauge
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Gauge
Service Reminder	Standard
Voltage Meter	Standard

STORAGE

Lockable Storage	Standard
Cupholder	Standard
Cupholder - Number Of Cupholders	2
Cargo Bed	Standard
Cargo Bed - Bed Length (in)	26
Cargo Bed - Bed Length (mm)	660
Cargo Bed - Bed Height (in)	11.5
Cargo Bed - Bed Height (mm)	292
Cargo Bed - Bed Width (in)	17.7
Cargo Bed - Bed Width (mm)	450
Cargo Bed - Bed Capacity (lbs.)	300
Cargo Bed - Bed Capacity (kgs.)	136.1
Cargo Bed - Cargo Bed Tilt	No
Cargo Bed - Integral Tie-Down Hooks	Yes
Glove Box / Dash Storage	Standard
Cargo Bed Cover - Camouflage Trim	No

LIGHTS

Headlight(s)	Standard
Headlight(s) - Type	LED

CONVENIENCE

Power Outlet	Standard
Seat Belts	Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	Yes

AUDIO & COMMUNICATION

CD Player - Number Of Discs

0

DRIVE LINE

Driveline	Standard
Driveline - Driveline Brand	On-Demand™
Driveline - Driveline Type	Selectable 4X2 / AWD
Driveline - Number Of Driveline Modes	2
Driveline - Rear Unlocking Differential	No
Driveline - Rear Solid Axle	No
Limited Slip Differential	Standard
Limited Slip Differential - Limited Slip Differential Location	Center

STEERING

Steering	Standard
Steering - Steering Type	Power
Steering - Steering Control	Steering Wheel
Tilt Steering	Standard

TOWING & HAULING

Trailer - Tilt	No
Trailer - Removable Tailgate	No
Trailer - Removable Sides	No

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
