Total Price: $1,399.00
* Plus Applicable Charges
Donate TOYS to Western NC!
ITEMS | SPEC |
Engine Mode | ZS154FMI-5 |
Engine Type | Single cylinder,4-stroke,air-cooling, camshaft upward, with balance shaft?tilting (10°leaned) |
Displacement(ml) | 123.67 |
Max.Power(kw/r/min) | ?6.3?1±10%??/?7500?1±5%?? |
Max.Torque (N.m/r/min) |
?8.8?1±10%??/?5500?1±5%?? |
Compression Ratio | 9.0:1 |
Bore and Stroke(mm×mm) |
54×54 |
Ignition method | CDI |
Lubrication method | Pressure and Splash |
lubricating oil | 15W/40-SE?-10TO 40?? HQB-10?<-10?? |
Starting method | E-START |
Clutch method | Automatic Wet Multi-Plate |
Gearshift Method |
Constant mesh, two stage transmission ,4-speed Gearshift |
TRANSMISSION | chain |
spark | A7RTC |
atv size | 1430×965×950 |
Wheelbase mm | 970±20mm |
wheels distance mm | front 750±15mm/ rear 760±15mm |
seat height mm | 700±15mm |
clearance mm | 180 |
Minimum turning circle radius mm | 2500±500mm |
sprocket | front 428-14; rear ?428-42 |
brake | fr & rear disc brake |
brake method | front and rear hand brake |
rim | front and rear 8 inch |
tyre | front?18×7-8/rear ?18×9-8 |
front suspension | oil dumper/270mm |
rear suspension | oil dumper/285mm |
height from foot padel to seat mm | 445±15mm |
front light | 2-12V/25W |
tail light | LED |
turning light | / |
carb | PZ19 |
oil tank | 7L |
frame | Double beam welded frame |
rear swing arm | Tube and plate structure |
max loading kg | 82 |
N W kg | 109 |
G W kg | 131 |
packing | steel frame+carton |
packing size | 1310×850×650 |
loading qty | 92pcs/40QH |
